SECTION 9 - SPECIFICATIONS
Specifications
Tank Capacity
275 in
3
9.6 lbs
4.5 L
4.4 kg
Width (W)
12.3 in
312 mm
Height (H)
16.7 in
424 mm
Depth (D)
23.9 in
607 mm
Melt Rate
11 lbs/hr
5 kg/hr
Pump Rate
60 lbs/hr
27 kg/kr
Gear Pump Control
Fixed speed
Pressure Relief
Single stage or optional pneumatic compound relief
Maximum Pressure
800 psi (55 bar)
Number of Hoses/Guns
1-2
Temperature Control
Microprocessor control and 7-day clock
Voltage
120VAC or 240VAC, 1PH, 50/60 Hz
Power Consumption
2400 W @ 120VAC; 4200 W @ 240VAC
Inputs
2 User Selectable Inputs Rated for 24VDC @ 15mA (Opto Isolated)
Outputs
1 User Selectable Output Rated for 250V/5A (Dry Contact Relay)
Applications
Packaging, non-wovens, converting applications
