VALCO MELTON D4-E - Tank Assembly Part Numbers

MM101 – D-4E HOT MELT UNIT 86
VALCO MELTON S.L.U. Pol. Ind. Agustinos C/G 34 3116 0 ORCOYEN, NAVARRA
TEL: +34 948 321580 Fax: +34 948 326584 melton@melton.es www.valcomelton.com
Nº Descripción Description Ref. Qty
1 Kit deposito D4-e D4-e tank kit 1
2 Subconjunto distribuidor D4-e D4-e tank assembly 1
3 Mazo termostato Thermostat bandle 029XX380 1
4 Terminal faston M-panel TE938 Terminal faston M-panel 1
5 Conjunto cables Cable assembly, heater pwr 029XX384 1
6 Brida sonda Probe flange 1
7 Junta torica viton 26.64x2.62 26.64x2.62 viton o’ring 1
8 Arandela grover M8 inox Stainless M8 grover washer 4
9 Arandela dentada M3 M3 washer 2
10 Tornillo allen M3x6 inox Stainless M3x6 allen screw 2
11 Tornillo allen M4x10 inox Stainless M4x10 allen screw 2
12 Tornillo allen M4x6 inox Stainless M4x6 allen screw 1
13 Tornillo hexagonal M8x100 inox Stainless M8x100 hexagonal screw 4
Tank Assembly
