MM101 – D-4E HOT MELT UNIT 85
VALCO MELTON S.L.U. Pol. Ind. Agustinos C/G 34 3116 0 ORCOYEN, NAVARRA
TEL: +34 948 321580 Fax: +34 948 326584 melton@melton.es www.valcomelton.com
Nº
Descripción Description
Ref.
Qty
1
Bastidor Frame
775XX858
1
2
Subconjunto depósito D4-e D4-e tank assembly
1
3
Subconjunto motor D4-e D4-e tank assembly
1
4
Conjunto acoplamiento rodillo Roller coupling assembly
783XX212
1
5
Subconjunto carcasa central D4-e D4-e central cover assembly
1
6
Subconjunto panel delanteroD4-e D4-e front panel assembly
1
7
Subconjunto panel trasero D4-e D4-e rear panel assembly
1
8
Arandela espaciadora Standoff
775XX857
4
9
Rejilla depósito Tank grid
782XX097
1
10
Junta deposito Gasket reservoir
782XX098
1
11
Chapa lateral izqda cuna Left lateral plate base
1
12
Sirga Lanyard, 12 in, nylon coated
781XX890
2
13
Fuente de alimentación Power source
1
14
Tarjeta de potencia Power board
Depending on
model
1
Tarjeta de potencia – 220VAC 220VAC - Power board
151XX606
Tarjeta de potencia – 115VAC 115VAC - Power board
151XX616
15
Arandela M4x48mm, M-H Standoff, M4x48mm, M-F
091XX601
8
16
Distancial Ø6x1/4” Spacer Ø6x1/4”
091XX417
4
17
Prensa PVC PG13 negro Press PVC PG13 black
2
18
Tuerca PVC PG13 negro Nut PVC PG13 black
2
19
Tornillo allen M4x10 inox Stainless M4x10 allen screw
4
20
Tuerca M6 Nut flange M6 zinc
784XX677
7
21
Arandela dentada M3 M3 washer
4
22
Tuerca hexagonal M3 inox Stainless M3 hexagonal nut
4
23
Tuerca hexagonal M4 inox Stainless M4 hexagonal nut
8
24
Tuerca hexagonal M6 inox Stainless M6 hexagonal nut
4
25
Tornillo cabeza redonda M6x10 BHCD, M6x10 LG,S.S.
784XX491
4
26
Remache pop 2.4x5.1 2.4x5.1 pop rivet
8
27
Arandela grover M6 inox Stainless M6 grover washer
8
28
Tornillo hexagonal M6x16 inox Stainless M6x16 hexagonal nut
4
29
Manta: aislante deposito Blanket: reservoir insulation
775XX860
1
