32. Electro---hydraulic power lift
1. 1. 1994
6000--8400 320 3
8. 11. 1990
Wiring diagram, ---662342
(E--models, see section34)
Note! See also picture on page 310/6. This diagram concerns
6000---8400 tractors up till the end of the year 1993.
S y m ---
bol Component Code
A1E Autocontrol electronic unit 70 --- 73
A2E Autocontrol, switch panel 74
A3E Compensator 70
B1E Position sensor 69
B2E Draft sensor, right 69
B3E Draft sensor, left 69
E1E Illumination, switch panel 74
E2E Illumination, position control knob 75
R1E Potentiometer, position control 74
S1E Push button, mudguard, lifting, right 71
S2E Push button, mudguard, lowering, right 71
S3E Push button, mudguard, lifting, left 70
S4E Push button, mudguard, lowering, left 70
S5E Push button, cabin, lifting 73
S6E Push button, cabin, lowering 73
S7E Switch, lowering speed 74
S8E Switch, transport height 74
S9E Switch, mixing/sensitivity 74
S10E Rocker switch, lift/lower 74
X2E Connector, 9 pins, supply, push buttons
Y1E Solenoid valve, lowering 69
Y2E Solenoid valve, lifting 69
Wire colours
Ru = brown
Pu = red
Ke = yellow
Si = blue
Mu = black
Vi = green
Va = white
Li = lilac
