37. Autocontrol 5.2 (K41107---)
1. 8. 2000
371 8
6250--8950
B.Tabletocheckvariousswitches(d01---d24)inthetestmodeinAC5.2
Activate the test mode FII (see page 370/8) and select with the DPS bush buttons the correct test point and confirm the selec-
tion with the DPS push button, after which the selected point can be checked. When the checking has been done, press
again the DPS pre---programming button, after which a new test point can be selected with DPS push buttons etc.
F
A
d
P
C
DIGITAL INPUT NAME IN DISPLAY 1 IN DISPLAY 0
d01 (S23) DPS push buttons, up Button depressed Button up
d02 (S23) DPS push buttons, down Button depressed Button up
d03 (S45) HiShift button (test both buttons) Button depressed Button up
d04 (S25) PTO---start, in cab PTOswitchinSTART---
position
Disengaged
d05 (S60) Seat switch Driver sits on the seat No signal
d06 (S9) Front clutch pedal limit switch Pedal in bottom Pedal up
d07 (S47) DPS automatic gear change switch Auto---position 1 Auto---position 2
d08 (S47) DPS auto/manual Auto 1 or 2 on DPS manual mode (man)
d09 (S40) Direction F, front controls F---direction selected Direction disengaged
d10 (S41) Direction R, front controls R---direction selected Direction disengaged
d11 (S51) DPS pre---programming button (under shut-
tle lever), front controls
Button depressed. Visi-
ble only for a while.
Button up
d12 (S28) PTO---speed 1 (lever in front position) Speed selected Speed disengaged
d13 (S29) PTO---speed 2 (lever in rear position) Speed selected Speed disengaged
d14 (S3W) Seat direction (TwinTrac only) Seat rearwards Seat forwards
d15 (S25) PTO rocker switch On , P T O --- s t a r t Disengaged
d16 (S15) Parking brake, front controls Parking brake applied Parking brake disengaged
d17 (S1A, S2A) PTO---startbuttononrearmudguard Button depressed Button up
d18 (S40) Direction F, reverse drive controls (TwinT-
rac only) *)
F---direction selected Direction disengaged
d19 (S41) Direction R, reverse drive controls (TwinT-
rac only) *)
R---direction selected Direction disengaged
d20 (S2W) Rear clutch pedal limit switch (TwinTrac) *) Pedal in bottom Pedal up
d21 (S51) DPS pre---programming button (TwinTrac)
*)
Button depressed. Visi-
bly only for a while.
Button up
d22 (S15) Parking brake, rear (TwinTrac) *) Parking brake applied Parking brake disengaged
d23 (S76) AutoTraction switch AutoTraction on AutoTraction off
d24 (S10, S20) Brake pedal position (brake light switches).
Check both front pedals separately. Possi-
ble rear brake pedal has not the switch.
Pedal in bottom Pedal up
*) Seat must be turned rearwards.
--- If the value in the display is not 0, althought it should be according to the table above, the switch can be damaged or in short
circuit. Check, change the switch. Check the switch wires.
--- If the value in the display is not 1, althought it should be according to the table above, the switch can be damaged/wires broken/
poor contacts in connectors. Change the damaged switch. Check the switch wirings.
