Message Window
Berifors 1990
10EXIT
1PARAMETERS 5SENSOR LOG
AC Communication link ver 1.0
hh:mm:ss
DIGITAL INPUTS
Steering angle J2:15 X
Main clutch J2:18 X
PS algorithm J2:17 X
Implement pos J2:20 X
Forward/Rev J2:10 X
Brake left J2:9 X
Brake right J2:19 X
Slip cntr 1/0 J2:16 X
Extra 3 J2:39 X
PS manual 1/0 J2:37 X
4WD A/M J2:14 X
4WD manual 1/0 J2:38 X
DL A/M J2:8 X
DL manual 1/0 J2:33 X
Extra 1 J2:34 X
PTO 1/0 J2:13 X
Extra 2 J2:35 X
PTO 540 1/0 J2:11 X
PTO 1000 1/0 J2:12 X
PS A/M J2:36 X
DIGITAL OUTPUTS
Slip control J1:18 X
4WD solenoid J1:38 X
4WD lamp J1:35 X
DL sol & lamp J1:37 X
Pto solenoid J1:21 X
Pto 540 lamp J1:1 X
Pto 1000 lamp J1:39 X
PS sol & lamp J1:36 X
Forward/Reverse J1:2 X
Extra 1 J1:23 X
Extra 2 J2:23 X
Implement dir J2:22 X
Implement act J2:24 X
Fuel preheater J1:22 X
Pieces counter J1:19 X
Parameter table no XX
Date of production XXXX
PROM Checksum XXXX
EPLD Version XX
FREQUENCY INPUTS
Flow J1:26 XXXX
Radar J1:7 XXXX
Gearbox J1: 30, 10 XXXX
Front axle J1: 29, 9 XXXX
Rear wheel J1: 27, 8 XXXX
Front wheel J1: 32, 13 XXXX
RPM impl J1:6 XXXX
RPM Engine J1: 31, 12 XXXX
RPM Pto J1: 28, 11 XXXX
PCS J1:25 XXXX
ANALOG INPUTS
Power lift J2:32 XXX
Outside temp J2:29 XXX
Acc pedal pos J2:7 XXX
Coolant temp J2:30 XXX
Implement pot J2:31 XXX
System volt J2:25 XXX
372
Model Code Page
34. Autocontrol ---III
15. 6. 1992
6600E, 8100E
342 2
Fault tracing chart on PC monitor
Service Program indicates the AC---III unit input and output
signals with the following marks:
--- X=nothing (see chart above)
--- E=error, short circuit or open circuit
--- 1 = c u r r e n t o n
--- 0 = c u r r e n t o f f
Markings after the names are ECS connector pins:
E.g. J2:15 = A2C pin 15
J1:18 = A1C pin 18
