155
Model Code Page
37. Autocontrol 5.2 (K41107---)
1. 9. 2002
371 5
6250--8950
1. 8. 2000
D. Fault codes in AC 5.2
Note! Concerning AC 5.2 fault code struc ture, see page 370/5 (AC 5).
Note! Concerning AC 5.2 fault functi on levels, see page 370/7 (AC 5).
Fault co-
de
Control
unit pin
Fault identification Fault
functi-
on le-
vel
Tests Repairs,
settings
P101 A1A4/6
Proportional valve P1 (Y4) of DPS takes current which exceeds or
goes below the given limits. Short circuit or wire damage (C1).
3
P103 A1A4/4
Proportional valve P2 (Y6) of DPS takes current which exceeds or
goes below the given limits. Short circuit or wire damage (C2).
3
l
in
r.
P105 A1A4/2
Proportional valve P3 (Y17) of DPS takes current which exceeds or
goes below the given limits. Short circuit or wire damage (C3).
3
Eonpa-
ge
.
C on pa-
ge
P107 A1A3/8
Forward drive proportional valve P4 (Y11) takes current which
exceeds or goes below the given limits. Short circuit or wire damage
(F).
3
371/9B.
370/21.
P109 A1A3/6
Reverse drive proportional valve P5 (Y12) takes current which
exceeds or goes below the given limits. Short circuit or wire damage
(R).
3
P125 A1A3/4
PTO proportional valve P6 (Y2) takescurrent whichexceedsorgoes
below the given limits. Short circuit or wire damage
2
P131 A1A3/2
Proportional output P7, which controls the starter interlock relay K52, takes
current which exceeds or goes below the given limits. Short circ uit or
wire damage
. Check the alternator.
1
P132 A1A3/1
Proportional output P8, which controls the 4WD relay K27, takes current
which exceeds or goes below the given limits. Short circuit o r wire
damage
(FET status error).
1
A128 A1A5/3
A1A5/6
Supply voltage of clutch and gas pedal position sensors is not within given
limits (4,5…5,5 VDC). Probably wires in short citrcuit.
3
A311 A1A5/2
Gearbox oil temperature value (sensor B14) impossible (over
+150˚C). Faultysensororitswiring
3
See instr.
A312 A1A5/2
Gearbox oil temperature value (sensor B14) impossible (below
--- 5 0 ˚C). Faultysensororitswiring.
3
See table
C on pa-
an
on page
371/13
A313 A1A5/4 Signal from gas pedal position sensor B15 below 0,4 VDC or over 4,4 VDC.
Sensor wrongly fitted or wire damages.
3
ge
.
and instr.
D on pa-
A314 A1A5/7 Signal from front clutch pedal position sensor B16 below 0,3 VDC or over 4,7
VDC. Sensor wrongly fitted or wire damages.
3
ge
371/14
A326 A1A1/1
A1A1/2
Control unit supply voltage not within limits 10,5…17,0 VDC. Battery damaged
or poor contacts or short circuit in wires. Check the alternator.
Low battery voltage causes the oil pressure drop and damages the multi---
disc clutches of the tractor shuttle and DPS.
3
A351 A1A7/1 Signal from rear clutch pedal position sensor B1W below 0,3 VDC or over 4,7
VDC. Sensor wrongly fitted or sensor/wire damages. This fault code appears
only when the seat is turned backwards.
3 See table
C on pa-
ge 371/9.
See instr.
B on pa-
ge
371/13.
d116 A1A5/9
A1A5/10
DPS up--down push buttons (S23) are active simultaneously. Push buttons in the
lever knobs may be in short circuit. The fault code can also appear, when the service
modes (FI--F III) are activated.
1
d117 A1A8/1
A1A8/2
Forward (S40) and reverse drive direction (S41) are active simultaneously. Shuttle
lever switches may be in short circuit.
4
d118 A1A8/4
A1A8/5
Both PTO speeds are engaged simultaneously. PTO lever switches (S28/S29) may
be in short circuit.
2
d123 A1A8/8
A1A8/1
A1A8/2
Front parking brake and one or both shuttle directions engaged simul-
taneously. Shuttle lever switches may be in short circuit.
No function, if
the seat has been turned rearward s.
4
See table
B on pa-
See table
B on pa-
d127 A1A8/8 Digital output, which controls the parking brake solenoid (Y18), is not within
given limits. Probably solenoid in short circuit or wire damages.
3
ge
. ge
370/20.
d129 A1A8/3
A1A2/5
DPS---pre---programming buttons S51 and S4W in front and reverse drive
controls active simultaneously. Front and rear push buttons in short circuit or
buttons have been stuck.
1
d130 A1A7/4
A1A2/9
PTO start switches (S25, S1A, S2A) in the cab and in the rear mudguard are simultaneously
active. Probably short circuit or switches have been stuck.
2
d152 A1A2/8
A1A2/7
In the reverse drive controls F and R directions active simultaniously. Shuttle
lever switches probably in short circuit. This fault code appears only when the
seat is turned backwards.
4
d133 A1A7/6
A1A2/6
Front and rear clutch pedal limit switches S9 and S2W active simultaneously . Probably short
circuit in the switches or switches have been stuck.
3
