A. Fitting AC 5 / 5.2 control unit on the trac tor
READY---PROGRAMMED
AC 5 CONTROL UNIT
FIT THE UNIT ON THE
TRACTOR
UNPROGRAMMED UNIT
FIT THE UNIT ON THE
TRACTOR
INPUT MAIN PROGRAM
INPUT PARAMETER FILE
SET-
TING
MODE
FIII
SETTING
MODE FIII
TEST
MODE
FII
SETTING
MODE FIII
INDEX 2
INDEX A
INDEX F
INDEX S/H
INDEX P
INDEX L
CALIBRATE CLUTCH PEDAL SENSOR
CALIBRATE REAR CLUTCH PEDAL SENSOR (in reverse
drive controls only),turn the seat at rear position before
calibration
SET DRIVING SPEED PARAMETER (tyres & transmission)
SET OUTDOOR TEMPERATURE UNIT (˚C/˚F)
SET DRIVING SPEED UNIT (km/h / miles/h)
SET PTO RATIO 1 (LEVER IN FRONT POSITION),
in program version 42 ---
SET PTO RATIO 2 (LEVER IN REAR POSITION),
in program version 42 ---
WARM THE TRACTOR +30˚...60˚C
(transmission oil temperature)
CHECK THROUGH THE WHOLE TEST MODE FII. ALL MUST BE OK
CALIBRATE GAS PEDAL SENSOR
SET THE SHUTTLE , DPS A N D PTO INITIAL PRES SURES
AND PRE---FILLING INDEXES (see page 370/24H (manual
setting) or automatic setting in AC 5.2 on page 371/11.Ma-
nual setting of PT O clutch, s ee page 371/12A (AC 5.2).
INDEX 1
T E S T --- R U N
After loading the main program file to a
control unit, the corresponding parame-
terfilemustbeloadedaswell.When
needed, a parameter file can be chan-
ged separately (if the control unit has
already the correct main program).
143
37. Autocontrol 5 / 5.2
1. 9. 2002
370 24A
6250--8950
1. 8. 2000
Modell Code Page
5. Working orders, AC 5 and 5.2
