Xe non headlight system,
dipped beam
Headlight system with sep arate bulbs for
dipped beam (inner bulb s) and m ain beam
(outer bulbs).
Xenon headlight system,
front indicator lights
1. Open bonnet and eng age support.
2. When replacing bulbs on the left-hand
side, open the cover of the fuse box. For
engine Z 13 DT
1)
, also pull the relay box
(located in front of the fuse box) up and
out of the guides.
When replacing bulb s on the right-hand
side, detach the air hose from the air
filter.
3. Rotate bulb holder to left and
disenga ge.
4. Push bulb into holder a little, rotate left
and remove.
5. Insert new bulb, without touching the
glass.
6. Engage holder into reflector by rotating
to the right.
7. After replacing bulbs on the left-hand
sid e, close the cover of the fuse box. For
engin e Z 1 3 DT
1)
, also position and
engag e the relay box.
After replac ing bulbs on the right-hand
sid e, reattach the air hose to the air
filter and engage.
The Xenon headlight dipped beam
op erates at very hig h voltage. Do not
touch the ignition system; danger to life.
We recomm end that you have the b ulbs
changed by your Vauxhall Authorised
Repairer.
1)
Sales designation – s ee page 234.
