21 3

2. Remove bulb from socket.

3. Insert new bulb.

4. Mount lens and engage in position.

Instrument illumination,

inf or mation dis play i llu min ation

3

We recommend that you have bulbs

changed by your Vauxhall Authorised

Repairer.
