1. Spray NACL Precision Optics Cleaner solution onto a clean, dry microfiber cloth.

2. Gently wipe the VLP-32C’s ring lens along the curve of the sensor, not top-to-bottom.

I.2 Cleaning Non-Optical Sensor Surfaces

Clean non-optical sensor surfaces with soapy water and a clean microfiber cloth. Follow the Cleaning Tips above. Avoid

getting electronic components, such as connectors and the PCB in the Interface Box, if present, wet.

Appendix I • Sensor Care 131
