Value Description

0 No PPS detected

1 Synchronizing to PPS

2 PPS Locked

3 Error

Table 9-4 PPS Status Byte Values

A position packet is shown in the figure below. Packet offsets are on the left, raw data bytes in hex are in the center, and the

ASCII interpretation is on the right.

Figure 9-4 Wireshark Position Packet Trace

Chapter 9 • Sensor Data 61
