7.4.4 GPS Connection Scenarios

Depending on the user’s application, the source of the NMEA message (and PPS) can be a GPS/INS receiver or a sub-

stitute device such as a laptop or microcomputer.

There are three common connection scenarios: connecting to a sensor from a Velodyne-supplied Garmin 18x LVC GPS

receiver, connecting to it from a computer's serial port, and connecting directly from a microcomputer’s UART.

7.4.4.1 Connecting a Garmin 18x LVC GPS Receiver

As an option, Velodyne LiDAR offers a Garmin 18x LVC GPS Receiver (P/N 80-GPS18LVC) pre-configured (per

Figure

7-6 below

) for optimized operation with your sensor. GPRMC is configured by default but GPGGA is also supported.

Figure 7-6 Garmin 18x LVC Configuration

44 VLP-32C User Manual
