Function Description

FPGA (bottom board)

Board — Top or Bottom board information.

Mode – Velodyne use only.

Type — Velodyne Use Only.

HW Version — Velodyne Use Only.

SOPC SYSID — Velodyne Use Only.

SW Version — Current operating firmware version.

Build — Velodyne Use Only.

Firmware Image Image — Firmware type (Failsafe and Application).

Firmware Version Version — Number of the stored Failsafe and Application images.

SOPC SYSID

Failsafe boot(00) — Velodyne Use Only.

Application hdlbot(03) — Velodyne Use Only.

GPS Position See description in

Table 10-1 on page 71

PPS See description in

Table 10-1 on page 71

Motor State See description in

Table 10-1 on page 71

Laser State See description in

Table 10-1 on page 71
