Integrated Services Card (ISC2) port descriptions and pinouts B-3

Appendix B: Trunk and Station Ports and Pinouts

Wave Server Installation Guide

Trunk 2

SLT 1

SLT 2

Pin Function Description

1 Not used

2 Ring Analog FXO trunk port 2

3 Tip Analog FXO trunk port 2

4 Not used

Pin Function Description

1 Not used

2 Ring Analog FXS station port 1 (failover)

3 Tip Analog FXS station port 1 (failover)

4 Not used

Pin Function Description

1 Alarm relay

2 Ring Analog FXS station port 2

3 Tip Analog FXS station port 2

4 Alarm relay

Release 4.0

June 20, 2013
