Analog Universal Module port descriptions and pinouts B-4
Appendix B: Trunk and Station Ports and Pinouts
Wave Server Installation Guide
Analog Universal Module port descriptions and pinouts
The Analog Universal Module is supported on both the Wave IP 500 and Wave IP 2500 Servers.
RJ-21X interface port descriptions and pinouts
Pin Function Pin Function Description
1 Ring 26 Tip Analog FXO trunk port 1
2 Ring 27 Tip Analog FXO trunk port 2
3 Ring 28 Tip Analog FXO trunk port 3
4 Ring 29 Tip Analog FXO trunk port 4
5 Ring 30 Tip Analog FXO trunk port 5
6 Ring 31 Tip Analog FXO trunk port 6
7 Ring 32 Tip Analog FXO trunk port 7
8 Ring 33 Tip Analog FXO trunk port 8
9-16 34-41 Not used
17 Ring 42 Tip Analog FXS station/DID Trunk port 1
18 Ring 43 Tip Analog FXS station/DID Trunk port 2
19 Ring 44 Tip Analog FXS station/DID Trunk port 3
20 Ring 45 Tip Analog FXS station/DID Trunk port 4
21 Ring 46 Tip Analog FXS station/DID Trunk port 5
22 Ring 47 Tip Analog FXS station/DID Trunk port 6
23 Ring 48 Tip Analog FXS station/DID Trunk port 7
24 Ring 49 Tip Analog FXS station/DID Trunk port 8
25 Ground 50 Ground Chassis ground
