Vertical WAVE IP 2500 - Required Tools

Site preparation 2-5
Chapter 2: Before You Begin
Wave Server Installation Guide
Wave IP 500-specific.
Wave IP 2500-specific.
Required tools
You need the following tools to install the Wave Server:
• #1 and #2 Phillips screwdriver
• Flat-head screwdriver
• Antistatic mat to protect electronic components from static electricity damage
• Antistatic wrist strap attached to a grounded, antistatic leash
Requirement Value or range
Heat emitted
Maximum 1980 BTU/hour
Power consumption
Maximum 580W
AC power source
Dedicated 15-amp circuit
AC power requirements,
T1 internal power supply
100-240 VAC, 50/60 Hz, 9A
AC power requirements,
180W external digital phone
power supply
100-240VAC, 50/60Hz, 2.4-1.2A
Requirement Value or range
Heat emitted
Base unit: Maximum 2830 BTU/hour
Each EXU: 910 BTU/hour
Power consumption
Base unit: Maximum 830W
Each EXU: 560W
AC power source
Base unit: Dedicated 15-amp circuit
Each EXU: 10-amp dedicated circuit
AC power requirements,
T1 internal power supply
Base unit: 100-120 VAC, 50/60 Hz, 9A
EXU: 6A
