Integrated Services Card (ISC2) port descriptions and pinouts B-2
Appendix B: Trunk and Station Ports and Pinouts
Wave Server Installation Guide
Integrated Services Card (ISC2) port descriptions and pinouts
The ISC2 is supported on the Wave IP 500 Server.
RJ-11 interface port descriptions and pinouts
Trunk 1
17 C 42 NC Alarm relay (reserved for future use)
18 C 43 NO Alarm relay (reserved for future use)
19-20 44-45 Not used
21 Ring 46 Tip Analog FXO trunk port 1 (failover)
22 Ring 47 Tip Analog FXO trunk port 2
23 Ring 48 Tip Analog FXO trunk port 3
24 Ring 49 Tip Analog FXO trunk port 4
25 Ground 50 Ground Chassis ground
Pin Function Description
1 Not used
2 Ring Analog FXO trunk port 1 (failover)
3 Tip Analog FXO trunk port 1 (failover)
4 Not used
Pin Function Pin Function Description
