Performing basic system configuration tasks 7-15
Chapter 7: Initial Configuration
Wave Server Installation Guide
8. In the New Address Range dialog, enter the Start IP address and End IP address.
Note: The IP address pool is defined with a range of IP addresses. The lowest two
addresses and the broadcast address (the highest address) in the range are reserved and will
never be assigned.
9. Click
OK to save your changes, and then return to the Global Administrator Management
Console.
Performing basic system configuration tasks
Important: If you configured Global Settings / General Settings via the Installation Wizard as
described in Chapter 6, you do not need to perform the steps in this section, unless you now
want to change any of those settings.
This section describes how to perform the following basic tasks:
• Enter basic system information. See page 7-15.
• Set the system date and time. See page 7-19.
• Configure the time service used by Wave ISM. See page 7-20.
Entering basic system information
Note the following about the information you enter according to the following instructions:
•
Company Name will be used for system-wide external caller ID if you select Send
Company Name and Main Number
on the the PBX tab in the General Settings applet.
Note: External Caller ID can be applied at three different levels: system-wide,
user-specific, and trunk-specific. System-wide external caller ID is the lowest in the
hierarchy and will be overridden by user-specific and trunk-specific settings. See
“Hierarchy of external Caller ID settings” in Chapter 16 in the Wave Global Administrator
Guide for more information.
• The Wave Server
Serial Number is used by the Software Licenses applet to verify that a
Wave software license is applied to the correct Wave ISM, and by Global Manager to
identify each Wave Server uniquely. Also, your Vertical technical support representative
may requests it while troubleshooting a problem.
