T1 Module (without serial interface) pinouts B-7
Appendix B: Trunk and Station Ports and Pinouts
Wave Server Installation Guide
T1 Module (without serial interface) pinouts
The T1 Module (without serial interface) is supported on both the Wave IP 500 and Wave IP
2500 Servers.
RJ-48X interface pinouts
E1 Module with serial interface port descriptions and pinouts
The E1 Module with serial interface is supported on both the Wave IP 500 and Wave IP 2500
Servers.
RJ-48X interface pinouts
50 CableType[0] 5-in-1 Cable Type Bit 0
51 Ground
52 Mode_DCE (DCE Mode)
53-55 Not used
56 Ground
57-60 Not used
Pin Function Pin Function
1 CI Receive Ring. - 5 CI Transmit Tip, +
2 CI Receive Tip,+ 6 Shield / Ground
3 Shield / Ground 7 Not used
4 CI Transmit Ring, - 8 Not used
Pin Function Pin Function
1 CI Receive Ring, - 5 CI Transmit Tip, +
2 CI Receive Tip, + 6 Shield / Ground
Pin Function
