Analog Trunk Module port descriptions and pinouts B-5
Appendix B: Trunk and Station Ports and Pinouts
Wave Server Installation Guide
Analog Trunk Module port descriptions and pinouts
The Analog Trunk Module is supported on both the Wave IP 500 and Wave IP 2500 Servers.
RJ-21X interface port descriptions and pinouts
T1 Module with serial interface pinouts
The T1 Module with serial interface is supported on both the Wave IP 500 and Wave IP 2500
Servers.
RJ-48X interface pinouts
Pin Function Pin Function Description
1 Ring 26 Tip Analog FXO trunk port 1
2 Ring 27 Tip Analog FXO trunk port 2
3 Ring 28 Tip Analog FXO trunk port 3
4 Ring 29 Tip Analog FXO trunk port 4
5 Ring 30 Tip Analog FXO trunk port 5
6 Ring 31 Tip Analog FXO trunk port 6
7 Ring 32 Tip Analog FXO trunk port 7
8 Ring 33 Tip Analog FXO trunk port 8
9-24 34-49 Not used
25 Ground 50 Ground Chassis ground
Pin Function Pin Function
1 CI Receive Ring. - 5 CI Transmit Tip, +
2 CI Receive Tip,+ 6 Shield / Ground
3 Shield / Ground 7 Not used
4 CI Transmit Ring, - 8 Not used
Release 4.0
June 20, 2013
