Connecting the analog station card 4-28
Chapter 4: Setting Up the Wave IP 2500 Server
Wave Server Installation Guide
Connecting the analog station card
The analog station card provides 24 analog FXS station ports. It is a full-width card that can be
installed in any universal slot.
See Appendix B, ”Trunk and Station Ports and Pinouts” for RJ-21X interface port descriptions
and pinout pairs for the analog station card.
To connect the analog station card:
1. Locate the RJ-21X port on the card.
2. Connect the RJ-21X cable from your punchdown block or multiport adapter to the port
on the Wave Server base unit using a male RJ-21X connector. See “Connecting an
RJ-21X cable” on page 4-21.
Connecting the digital station card
The digital station card provides 24 or 48 digital station ports. It is full-width card that can be
installed in any universal slot.
See Appendix B, ”Trunk and Station Ports and Pinouts” for RJ-21X interface port descriptions
and pinout pairs for the digital station card.
Note: The 48-port digital station card has two RJ-21X connectors with 24 ports available on
each.
To connect the 24- or 48-port digital station card:
1. Locate the RJ-21X port(s) on the card.
2. Connect the RJ-21X cable(s) from your punchdown block or multiport adapter to the
port(s). See “Connecting an RJ-21X cable” on page 4-21.
