System LED indicators C-3
Appendix C: Integrated Services Card Status LEDs
Wave Server Installation Guide
System LED indicators
This appendix lists System Status LED indicators and/or Card Status LED indicators that you
may observe for the following scenarios:
Normal boot sequence
System shutdown
Error condition
Important: Not all System LED indicators are described in this appendix. For a complete
explanation of all of the potential LED activity that you may observe for a variety of
scenarios, see Appendix E in the Wave Server Hardware Reference Guide.
Normal boot sequence indicators
After the Wave Server is powered on, you will observe the following LED indicator sequence
during a normal boot sequence.
The
Expected time column indicates the length of time that a specific LED pattern is displayed
before moving on to the next pattern in the sequence. “~” indicates an approximate expected
time. For settings with complex blink patterns, see Appendix E in the Wave Server Hardware
Reference Guide for detailed patterns and timings.
SYSTEM STATUS LEDS CARD STATUS
LEDS
Current status Expected
time
LED1 LED2 LED3 LED4 Red
LED
Green
LED
ISC1
/ISC2 boot
loader LED Lamp
Test (red LEDs).
0.5 sec Red Red Red Red Red off
ISC1
/ISC2 boot
loader LED Lamp
Test (green LEDs).
0.5 sec Green Green Green Green off Green
ISC1/ISC2 boot
loader early boot
initialization and
Flash verification.
~15 sec Red off off off off off
Release 4.0
June 20, 2013
