System LED indicators C-4
Appendix C: Integrated Services Card Status LEDs
Wave Server Installation Guide
ISC1/ISC2 boot
loader is waiting for
PLD Programmer
on VAM to connect.
~15 sec
with 1.5
GHz VAM
Red Blinking
green
off off off off
This pattern may be displayed for up to 150 seconds. Timing can be affected by BIOS memory
test, or the Windows Troubleshooting and Advanced Startup menu appearing due to a failure to
start Windows on the previous boot.
PLD Programmer
has connected to the
ISC1/ISC2 boot
loader and is
verifying the
embedded firmware
image.
~12 sec Red Green off off off off
ISC1
/ISC2 boot
loader is loading
Linux kernel image
into memory.
~5 sec Red Green Green off off off
ISC1
/ISC2 boot
loader is transferring
execution control to
Linux.
~2 sec Red Green Green Green off off
Linux started. ~6 sec Green Alterna-
ting
flicker-
ing red
on green
back-
ground /
green
off off off off
LED Manager
started.
~5 sec Green off off off Blinking
red
off
SYSTEM STATUS LEDS CARD STATUS
LEDS
Current status Expected
time
LED1 LED2 LED3 LED4 Red
LED
Green
LED
