Vertical WAVE IP 2500 - Page 205

System LED indicators C-5
Appendix C: Integrated Services Card Status LEDs
Wave Server Installation Guide
Check Disk in
progress.
0 sec (or
several
minutes if
Check Disk
occurs.)
Green Alterna-
ting red /
green
off off Blinking
red
off
Windows is loading. ~2 min Green Blinking
red
off off Blinking
red
off
Windows is up. ~5 sec Green Green off off Blinking
red
off
Loading basic PBX
services.
~4 min Green Green Blinking
red
off Blinking
red
off
Basic PBX services
are up. Phone calls
can now be made.
~5 sec Green Green Green off Blinking
red
off
Loading advanced
PBX services.
~6 min Green Green Green Blinking
red
Blinking
red
off
System is fully
booted and
operational.
Indefinitely Green Alterna-
ting
flicker-
ing red
on green
back-
ground /
green
Slow
blinking
green
Blinking
green
off Blinking
green
SYSTEM STATUS LEDS CARD STATUS
LEDS
Current status Expected
time
LED1 LED2 LED3 LED4 Red
LED
Green
LED
Release 4.0
June 20, 2013
