E1 Module with serial interface port descriptions and pinouts B-8
Appendix B: Trunk and Station Ports and Pinouts
Wave Server Installation Guide
DB-60 interface pinouts
3 Shield / Ground 7 Not used
4 CI Transmit Ring, - 8 Not used
Pin Function
1-16 Ground
17 RD- (Receive Data)
18 RD+ (Receive Data)
19 TxC+ (Send SCT)
20 TxC+ (Send SCT)
21 RxC (Receive SCR)
22 RxC (Receive SCR)
23-26 Not used
27 TxD (Send SD)
28 TxD (Send SD)
29 Not used
30 Ground
31-32 Not used
33 LL (Loopback Test)
34 DTR (Data Terminal Ready)
35 RTS (Request to Send)
36-41 Not used
42 CTS (Clear to Send)
43 DSR (Data Set Ready)
44 DCD (Data Carrier Detect)
Pin Function Pin Function
Release 4.0
June 20, 2013
