Vertical WAVE IP 2500 - Page 199

Digital Station Module port descriptions and pinouts B-13
Appendix B: Trunk and Station Ports and Pinouts
Wave Server Installation Guide
17 Ring 42 Tip 12-port model: Not used
24-port model: Digital station port 17
18 Ring 43 Tip 12-port model: Not used
24-port model: Digital station port 18
19 Ring 44 Tip 12-port model: Not used
24-port model: Digital station port 19
20 Ring 45 Tip 12-port model: Not used
24-port model: Digital station port 20
21 Ring 46 Tip 12-port model: Not used
24-port model: Digital station port 21
22 Ring 47 Tip 12-port model: Not used
24-port model: Digital station port 22
23 Ring 48 Tip 12-port model: Not used
24-port model: Digital station port 23
24 Ring 40 Tip 12-port model: Not used
24-port model: Digital station port 24
25 Ground 50 Ground Chassis ground
Pin Function Pin Function Description
Release 4.0
June 20, 2013
