About the Wave IP 500 Server 3-4
Chapter 3: Setting Up the Wave IP 500 Server
Wave Server Installation Guide
About the ISC2
The ISC2 includes the following:
• Embedded Intel IXP processor
• Fault Monitor Module
• Digital Signal Processor (DSP)
• Media Resource Module (MRM) connector for an optional MRMA module for expanded
DSP functionality
• 2 analog station ports (RJ-11 connectors)
• 2 analog trunk ports, loop-start only (RJ-11 connectors)
• 1 external Ethernet switched port, 10/100Base-T.
• 2 USB host ports for communication to the VAM (type A connectors)
• 1 USB device port for service console connection to the embedded processor (type
mini-B connector)
• 1 audio input port for an external music-on-hold source
• 1 audio output port for an external paging system
• 4 system status LEDs and 2 module status LEDs, described in detail in Appendix C
• Power on/off button
• Reset button
• Internal 56K soft modem
• 1 station to trunk power fail connection relay
• 1 alarm relay
