Installing expansion components 3-16
Chapter 3: Setting Up the Wave IP 500 Server
Wave Server Installation Guide
To install modules:
1. Unplug the Wave Server’s power cord, but do not disconnect the grounding wire.
2. Remove the plastic bezel that covers the front of the Wave IP 500. To do so, grasp the
tabs of the bezel on both sides and pull forward.
3. Remove the blank module faceplate.
4. Insert modules and cards carefully.
5. Seat the module properly for good electrical connection. Engage the module by pressing
gently on it—be sure to press on the faceplate, not a connector or component on the
module.
6. Install blank faceplates on all unused slots.
7. Replace the plastic bezel on the front by aligning it and pressing on both ends until it
snaps into place.
8. Reconnect the Wave Server to power.
Module status LEDs
Each module has a pair of LEDs that indicate the component’s status:
Status Red LED Green LED
System is in an early boot phase. off off
System boot is in progress, or a firmware flash
update is in progress.
Blinking red off
System is operational with no errors. off Blinking green
System shutdown is in progress. Blinking red Blinking green
Error condition exists on the system. Red off
System upgrade is in progress. Blinking red Green
Hard drive imaging in progress (via the Wave
System Recovery Disk.)
Red Green
Release 4.0
June 20, 2013
