Connecting a DSS Console 4-31
Chapter 4: Setting Up the Wave IP 2500 Server
Wave Server Installation Guide
There are two ways to connect the DSS Console:
• To a digital station port on any of the following modules or cards on the Wave IP 2500:
• 12-Port Digital Station Module (VW-12DS2-M)
• 24-Port Digital Station Module (VWU-24DS2-M)
• 48-Port Digital Station Card (VW-48DS2-C) for Edge 700/Vodavi Phone support
Connecting a DSS Console to a digital station port requires a separate digital station port
for the digital phone associated with the DSS Console. In this configuration, there is no
physical connection between the DSS Console and the user’s digital phone.
• Directly to an Edge 700 - 24 button digital phone. In this configuration, the digital
phone and DSS Console share a single cable run from the user’s desk to the Wave Server.
Only one digital station port is required.
Note: Only one DSS Console can be connected directly to the digital phone. Up to 4
additional DSS Consoles that are each connected to a digital station port as described
above can be associated with that digital phone.
For instructions on how to configure a DSS Console for a user, see “The Phone \ DSS Consoles
tab” in Chapter 11 in the Wave Global Administrator Guide.
To connect a DSS Console to a digital station module or card:
1. Locate an unused port on the digital station module or card.
2. Connect the DSS Console to the digital station port using an RJ-11 cable. The maximum
cable length between the Wave Server and the DSS Console is 1968 feet (600 m).
To connect a DSS Console directly to an Edge 700 - 24 button digital phone:
1. On the back of the digital phone, locate the port labeled ADP.
2. Connect the DSS Console to the ADP port using an RJ-11 cable.
