7.13 BCB Reference Current and Connection
Table 7.4 below provides recommended BCB rated current and battery maximum discharge current at full load. Refer to
Table 3B in IEC60950-1, and select appropriate cable CSA according to local electrical codes and standards.
Item s Unit
UPS rated pow er (kV A)
100 12 0 150 160 200 250
28-block
battery
Maximum battery discharge current at full
load
A 376 420 525 560 700 880
Reference rated current of BCB A 400 500 630 630 800 1000
CSA of connection cable mm
2
150 185 2*150 2*185 2*240 2*240
30-block
battery
Maximum battery discharge current at full
load
A 350 420 525 560 700 880
Reference rated current of BCB A 400 500 630 630 800 1000
CSA of connection cable mm
2
150 185 2*150 2*185 2*240 2*240
32-bolck
battery
Maximum battery discharge current at full
load
A 330 394 492 525 656 825
Reference rated current of BCB A 400 400 500 630 800 1000
CSA of connection cable mm
2
150 185 2*150 2*185 2*240 2*240
34-block
battery
Maximum battery discharge current at full
load
A 308 370 463 494 617 776
Reference rated current of BCB A 400 400 500 500 800 800
CSA of connection cable mm
2
150 185 2*150 2*185 2*240 2*240
36-block
battery
Maximum battery discharge current at full
load
A 290 350 437 466 583 733
Reference rated current of BCB A 400 400 500 500 630 800
CSA of connection cable mm
2
150 185 2*150 2*185 2*185 2*240
38-block
battery
Maximum battery discharge current at full
load
A 276 330 414 442 552 694
Reference rated current of BCB A 400 400 500 500 630 800
CSA of connection cable mm
2
150 185 2*150 2*185 2*185 2*240
40-block
battery
Maximum battery discharge current at full
load
A 262 315 393 420 525 660
Reference rated current of BCB A 400 400 400 500 630 800
CSA of connection cable mm
2
150 185 2*120 2*150 2*185 2*240
42-block
battery
Maximum battery discharge current at full
load
A 250 298 374 398 497 626
Reference rated current of BCB A 400 400 400 400 630 800
Table 7.4 BC B rated curren t and battery m ax. discharge current at full load (recom m ended)
