9.2.16 Input/output Switch Kit
As shown in Figure 9.13 below, the I/O switch kit includes input switch, output switch and bypass switch. Please dismantle the
shorting busbar before installation, then install the switches to corresponding shorting busbars.
Figure 9.13 Schem atic d iagram of I/ O sw itches
N O. Description
1 Input switch
2 Bypass switch
3 Output switch
