Item Unit
Ra ted po wer (kV A)
100 12 0 16 0 200 2 50
Transient voltage response % ±5
Total voltage harmonic distortion % < 1 (linear load), < 3 (non-linear load
3
)
Synchronization window Hz
Upper limit: 0.5Hz, 1Hz, 2Hz, 3Hz, +10%; Default: +10%.
Lower limit: -0.5Hz, -1Hz, -2Hz, -3Hz, -10%; Default: -10%
Slew rate (max. change rate of synchronization
frequency)
Hz/s 0.6; setting range: 0.1 ~ 3
Table 12.6 Inverter output (to critical load) (con tinued )
N O T E:
1. Factory set to 38 0 V, 400V or 415V can be selected b y service eng ineer at site.
2. Factory set to 50H z or 60 H z can be selected by service engineer at site. Note that th e system
freq u ency can be changed only w hen the U PS is on bypass. It is strictly p rohibited to change the
system freq uency when the U PS is on inverter.
3. EN 50091-3 (1.4.58) crest facto r 3:1, non-linear load.
12.7 Electrical Characteristics (Bypass Input)
Item Unit
Ra ted po wer (kV A)
100 120 160 200 250
Rated AC voltage
1
Vac
380/400/415, 3-phase 4-wire, sharing neutral with the rectifier input and providing neutral reference
to the output
Rated current
380V A 152 182 243 303 379
400V A 145 174 232 290 362
415V A 139 166 222 278 347
Frequency
2
Hz 50/60
Bypass voltage tolerance %Vac
Upper limit: +10, +15 or +20, default: +15
Lower limit: -10, -20, -30 or -40, default: -20
(delay time to accept steady bypass voltage: 10s)
Bypass frequency tolerance % ±10
Table 12.7 Bypass input
N O T E:
1. Factory set to 38 0 V, 400V or 415V can be selected b y service eng ineer at site.
2. Factory set to 50H z or 60 H z can be selected by service engineer at site.
