5.6 Status Bar Component
The status bar indicates UPS status by:
• scrolling messages to inform viewers; see Table 5.1 below through Table 5.3 on page97
• changing color; green for normal, yellow for warning and red for alarm.
• showing an icon inside the bar; shown at right.
5.6.1 Status Bar Messages
Up to three messages may scroll through the status bar to the right of the status icon. Each message will have a duration of
four seconds, except they change immediately if the system’s status changes.
M essage 1 M essage 2 M essage 3 D efinitio n
Load on inverter
Frequency converter
mode active
Output frequency X Hz
This system is in normal operating mode, supplied by the
inverter and operating as a frequency converter
Load on inverter
Energy saving mode
active
/
This system is in normal operating mode, supplied by the
inverter, and has one of the energy-saving modes active
Load on inverter Operation normal /
This system is in normal operating mode, supplied by the
inverter, and has no special configurations
Load on bypass
Energy saving mode
active
/
This system is in normal operating mode, supplied by the
bypass, and has one of the energy-saving modes active
Load on battery Battery test in progress /
This system is in normal operating mode, supplied by the
inverter via the battery, and a battery test is actively
running
Load off
Energy saving mode
active
/
This parallel system is in normal operating mode, load not
supplied by this unit, and has one of the energy-saving
modes active
Load on inverter Test mode active /
This system is in normal operating mode, for the test
mode that is activated
Table 5.1 N orm al status m essages
5 Operator Control and Display Panel
95
Vertiv™ Liebert® EXM2 UPS User Manual
