9.2.2 Bypass Short-circuit Withstand Option
As shown in Figure 9.4 below, the bypass short-circuit withstand option contains three bypass fuses. Before installation, it is
necessary to remove three bypass shorting copper bars and then install three bypass fuses at the corresponding shorting
copper bars.
Figure 9.4 Bypass short-circuit w ithstan d option
N O. Description
1 Bypass short-circuit withstand options
