9.2.5 Seismic Anchor Kit
The UPS provides seismic anchor kits that can support earth quake intensity level 9 and below to avoid and reduce the
damage to UPS caused by earthquake vibration
See Table 9.2 below for dimensions of the seismic anchor kit.
Se ismic a nch or W idth (m m ) Length (m m ) T orq ue v alue (N .m )
Seismic anchor 60 585 13
Table 9 .2 Dim ensions of the seism ic anchor kits
Fix the UPS onto the concrete floor.
W A RN IN G!
1. Only Vertiv authorized engineers shall carry out th e installation.
2. C arry out the installation strictly follow ing the instructions. Failu re to observe this could
cause person nel inju ry or dam age to the UP S and seism ic anchor kits.
Preparation
1. Prepare the installation tools, including a cross head screwdriver, a torque spanner and an adjustable spanner.
2. Check that all installation materials are present and complete, including two seismic anchors, eight M8 × 25
tapping screws, six M12 expansion bolts.
Pro cedures
The installation procedures are as follows:
1. Use M8 × 25 tapping screws (4 pcs) to install seismic anchor on the rear bottom of the UPS cabinet, and use M12
expansion bolts (3 pcs) to fix seismic anchor on the ground, as shown in Figure 9.5 on the next page
