9 Options
This chapter provides the UPS option list, and introduces the functions, installation and configuration of each option.
9.1 Option List
N o. O ption na m e Rem ark
1 Side cabinet for top cabling Top cable entry (+300mm width)
2 Battery temperature sensor kit
3 Bypass short-circuit withstand kit Withstand increased up to 65kA
4 Seismic anchor kit Common for 100kVA ~ 250kVA
5 IS-UNITY-DP card Intellislot ports 1 ~ 2
6 IS-UNITY-LIFE card Intellislot ports 1 ~ 2
7 SIC card (Available only in selected region) Intellislot ports 1 ~ 2 (port 1 recommended)
8 IS-Relay card Intellislot ports 1 ~ 2
9 485 card Intellislot ports 1
10 Battery ground fault assembly
11 Parallel cable Available in 5m, 10m, 15m
12 LBS cable Available in 10m, 15m, 20m
13 BCB box
14 Back-feed contactor option
15 Top fan assembly Front to top ventilation without height increase
16 I/O switch assembly Includes input, output and static bypass switches
17 IP21 option
18 IP31 option
19 Transformer
20 C2 electromagnetic shielding option
21 CPSS model
22 LBS adapter
Table 9 .1 O ption list
N O T E: T he R S 232 of Intellislot 2 shares com m unication resources w ith th e RS485 o f the H M I RJ45
interface. To avoid conflicts, when u sing the H M I interface to com m unicate w ith BM S, the Intellislot
interface 2 can only connect to the IS-Relay card.
