4.1.10 Power Cable Connection Steps
Connection term inal
Figure 4.2 belowshows the connection terminals of the UPS power cable. Figure 4.2 below show the power cable entry and
routing methods.
N O T E: T he pow er cables should be routed throug h tunnels or cable troughs to prevent cable dam age
due to m echanical stress.
N O T E: W hen routing the cables insid e the cabinets, it is required to bind an d fix the cables as
instructed in Figure 4.3 on pag e44 to Fig u re 4.5 on page47 in the cabinets, so as to prevent cable
dam age due to m echan ical stress.
Figure 4.2 Power cable connection term inals
Pow er cab le connection term inals of 10 0kVA ~ 160kVA U P S
N O. D esc rip tio n NO. D esc rip tio n
1 bA 6 oC
2 bB 7 oB
3 bC 8 oA
4 mA 9 N
5 mB 10 mC
