Vertiv Liebert EXM2 - Operation; Log in to the Vertiv Liebert EXM2 Touchscreen Control Panel

5.3 Operation
5.3.1 Log In to the Vertiv Liebert EXM2 Touchscreen Control Panel
The Vertiv™ Liebert® EXM2 Touchscreen Control Panel is On whenever the UPS has control power. It may be inactive and
appear dark, depending on its settings. If it is inactive, touch the TOUCHSCREEN to wake it up.
To log in to the Vertiv Liebert EXM2 Touchscreen Control Panel:
1. Touch the icon at the top right of the screen. The lock and background will change color and open the PIN
REQUIRED screen, which has a keypad.
2. Enter a PIN at the screen below.
3. Touch Enter
N O T E: E ntering an incorrect PIN will generate a screen saying the num b er is invalid.
Figure 5.10 Log in screen
5 Operator Control and Display Panel
66
Vertiv™ Liebert® EXM2 UPS User Manual
