Victory 2009 VISION User Manual

148
MAINTENANCE
Maintenance
Belt Tension Measurement Procedure
1. Safely elevate and support the motorcycle with
the rear tire 1-2 inches off the floor (see
page 200).
2. Place the transmission in neutral.
3. Rotate the rear wheel in a forward direction until
the valve stem is at the bottom. This is your
reference point for determining the tight spot to
make your adjustment (if necessary).
4. Position the small O-ring on the tension gauge
directly over the 10 lbs. mark on the plunger as
shown in Fig. 1 on page 147.
5. Place a tape measure or steel rule next to the
drive belt as shown in Fig.2, at a position mid-
way between the sprockets. Support the rule or
tape so it does not move from this position.
Fig. 2
visionownersmanual.book Page 148 Wednesday, February 13, 2008 4:31 PM

Victory 2009 VISION Specifications

General

Year	2009
Manufacturer	Victory
Model	VISION
Category	Touring
Compression Ratio	9.4:1
Cooling System	Air / oil
Transmission	6-speed
Final Drive	Belt
Front Tire	130/70-R18
Rear Tire	180/60-R16
Engine Type	V-twin, four-stroke
Displacement	1731 cc
Bore x Stroke	101 x 108 mm
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Rear Suspension	Single
Front Brakes	Dual 300mm discs, 4-piston calipers
Rear Brakes	Single 300mm disc 2 piston caliper
Seat Height	26.5 inches
Fuel Capacity	22.7 liters / 6.0 US gallons
Wheelbase	65.7 inches
