Vigilant MX1 Operator Manual Document: LT0344
Page 11-6 8 August 2017 Issue 2.4
If the internal checking routines detect an inconsistency then
this point is put into fault. Refer to the history and/or printer log
for "Sw Fault" events that give more detail as to the type of
fault. Note some faults will automatically clear and others may
need this point to be reset to clear the fault. Irrespective of this,
occurrences of a software fault should be advised to the service
company for assessment.
Provides the status of configuration data file1. The point state is
Fault if a CRC check of configuration data file1 fails, otherwise
the state is Normal.
Provides the status of configuration data file2. The point state is
Fault if a CRC check of configuration data file2 fails, otherwise
the state is Normal.
Provides the status of the controller firmware. The point state is
Fault if a CRC check of the firmware fails, otherwise the state is
Normal.
Provides the status of the Controller boards RAM. The point
state is Fault if an error is detected with the RAM, otherwise the
state is Normal.
Point is unused but included for future enhancement.
Point is unused but included for future enhancement.
Point is unused but included for future enhancement.
Point is unused but included for future enhancement.
This point indicates that there are one or more foreign RZDUs
detected in the system. The point state is Fault if a reply is
received from an RZDU with an address that corresponds to an
RZDU that is not enabled in the configuration data file. The fault
will automatically clear if replies from the foreign RZDU stop
being received.
Provides status of the MX1 Commission Test function, for recall
on the LCD and to light the Tests indicator on the keypad.
When Commission Mode is active, the status of this point will
show ActInput and TestOp. Otherwise it will show Normal.
This point signals Fault for 12 seconds following restart of the
panel. This includes cold starts, user initiated reboots, and
system controlled or uncontrolled watchdog restarts. The
Startup Flags status can be used to ensure that a fault is sent to
the brigade signalling equipment, or not.
This point signals fault if the MX1 has what appears to be an
uncorrupted configuration data file but which contains compiled
Output Logic with fatal problems. If this fault is signalled, the
ability of the MX1 to act as a fire alarm is severely
compromised. The MX1 firmware will force the System Fault
and Faults indicators on, and will force the fault relay into its de-
energised state. This fault can only be corrected by restarting
the panel using a configuration data file with output logic
compiled without the problem, which could be either the
alternative configuration data file stored in the MX1 or a newly
downloaded configuration data file.
This point signals when the AIF is in attended mode.
This point is disabled if the printer output is disabled.
Point is unused but included for future enhancement.
