Vigilant MX1 - Displaying Zone or Point Command Menu; Resetting Zones or Points

Vigilant MX1 Operator Manual Document: LT0344
Page 6-2 8 August 2017 Issue 2.4
This function requires Access Level 2.
From any of the recall point or zone status displays described in Chapter
5, you can press MENU or MENUF4 to see the commands available for
the currently displayed item.
Alternatively, for a zone, press ZONE or for a point press
ZONE twice from the base display or Alarm List. Enter the
required zone or point number and press the OK key. This
will show the recall status display for that zone or point.
For example, in a point recall display pressing MENU will show a menu
of commands.
Fig 6-1 – Recall Point Status Display
 RESETF1 will reset the displayed point. See the next section for
more detail.
 DISABLEF2 will disable or enable the displayed point. See page 6-
6 for more detail.
 TESTF3 will test the point. See pages 6-12 and 6-16 for more
detail.
 VALUESF4 will display analogue values for a point. See page 6-18
for more detail. This option is not displayed for a zone.
Pressing MENU again will switch back to the Recall Point or Zone Status
display.
From the recall zone status display, press MENU or MENUF4 to display
the zone menu commands.
Press RESETF1 or RESET to reset the zone.
Displaying Zone or Point Command Menu
Resetting Zones or Points
Resetting a
Zone
P
1
.
1
.
0
MIM
800
MX Device
|
RESET
Office
|
DISABLE
Normal
|
TEST
|
VALUES
