The following tables list the default Point text and a description of all the
in-built points. Some MX1 configurations may have these points
changed or deleted.
This point indicates the Alarm Devices status and is used to
enable/disable the Alarm Devices. "Alarm Devices" are devices
(e.g. sounders and sirens) that operate to signal to building
occupants that a fire is present and the area should be
evacuated. The state of the Alarm Devices is controlled by
output logic, such that it is operated when there is an alarm on
a non-disabled zone that is mapped to the Alarm Devices.
When the Alarm Devices are disabled, the Alarm Devices point
indicates disabled and the Alarm Devices Disabled/Fault LED
on the MX1 front panel is on steady, i.e. enabling/disabling this
point enables/disables the alarm devices. If the Alarm Devices
point is in fault, then the Alarm Devices Disabled/Fault LED on
the front panel flashes (if the Alarm Devices point is not
disabled). Do not disable the Alarm Devices to stop signalling of
an Alarm Devices fault since this will also prevent the alarm
devices from operating. Disable the source of the fault. This
point does not indicate if Trial Evac or Silence Alarms are
active. When the Alarm Devices are test operated, this point
indicates a status of "TestOp".
Provides the status of the G.P IN 1 input (J2-1).
Provides the status of the G.P IN 2 input (J2-2).
GPOUT1 is an open collector output (J7-1) with supervision
capability. The Operate state of the output can be controlled by
system or user logic. If supervision has been enabled in the
configuration then the Fault state is determined and shown by
the supervision input point GPOUT1S.
GPOUT1S is the supervision point for GPOUT1. If supervision
is enabled on GPOUT1 then the Fault state of the output will
show on this point. If GPOUT1 is not used then this point can
be used as an input.
GPOUT2 is an open collector output (J7-2) with supervision
capability. The Operate state of the output can be controlled by
system or user logic. If supervision has been enabled in the
configuration then the Fault state is determined and shown by
the supervision input point GPOUT2S.
GPOUT2S is the supervision point for GPOUT2. If supervision
is enabled on GPOUT2 then the Fault state of the output will
show on this point. If GPOUT2 is not used then this point can
be used as an input.
ANC1 is an ancillary relay with supervision capability (J4). The
Operate state of the point can be controlled by system or user
logic to energise the relay. If supervision has been enabled in
the configuration then the Fault state is determined and shown
by the ANC1S (241.9) point.
ANC1S is the supervision input (J4-5) for ancillary relay 1. If
supervision is enabled on ANC1 then the Fault state of the
output will show on this point. If supervision is not enabled on
ANC1 then ANC1S is a clean contact input with states
determined by the configuration.
Equipment Point Descriptions
Equipment 241
– MX1
Controller
