Document: LT0344 Vigilant MX1 Operator Manual
Issue 2.4 8 August 2017 Page 11-3
ANC2 is an ancillary relay with supervision capability (J5). The
Operate state of the point can be controlled by system or user
logic to energise the relay. If supervision has been enabled in
the configuration then the Fault state is determined and shown
by the ANC2S (241.11) point.
ANC2S is the supervision input (J5-5) for ancillary relay 2. If
supervision is enabled on ANC2 then the Fault state of the
output will show on this point. If supervision is not enabled on
ANC2 then ANC2S is a clean contact input with states
determined by the configuration.
ANC3 is an ancillary relay with supervision capability (J6). The
Operate state of the point can be controlled by system or user
logic to energise the relay. If supervision has been enabled in
the configuration then the Fault state is determined and shown
by the ANC3S (241.13) point.
ANC3S is the supervision input (J6-5) for ancillary relay 3. If
supervision is enabled on ANC3 then the Fault state of the
output will show on this point. If supervision is not enabled on
ANC3 then ANC3S is a clean contact input with states
determined by the configuration.
This point is unused and included for future enhancement only.
This point is intended to represent the "FIP PWR NORM-" PIN
(J8-7) on the Brigade Signalling Interface. This open collector
output is operated when power is supplied to the panel and de-
operated when power is removed. There is no link between this
point and the actual output.
Provides the status of the "FIP COMMS OK-" PIN (J8-6) of the
Brigade Signalling Interface. S/C to 0V gives the Normal state
and O/C gives the Fault state.
The Operate state controls the "FIP ISOL-" PIN (J8-8) on the
Brigade Signalling Interface, the DISABLE/ISOL relay (J11) and
the isolate component of the ASE+ signal on the ASE Interface
(J12).
The Operate state controls the "FIP FIRE" PIN (J8-4) on the
Brigade Signalling Interface, the FIRE/ALM relay (J11) and the
fire component of the ASE+ signal on the ASE Interface (J12).
The Operate state is OR-ed with the Fault state of the points
RAM test, DB1 CRC Fault, DB2 CRC Fault, FW CRC, S/W
Faults and also a check on whether output logic is running, and
then controls the "FIP DEF-" PIN (J8-1) on the Brigade
Signalling Interface, the FAULT/DEF relay (J10) and the fault
component of the ASE+ signal on the ASE Interface (J12).
Provides the status of the "Brigade Test-" PIN (J8-2) of the
Brigade Signalling Interface. S/C to 0V gives the ActiveInput
state and an O/C gives the Normal state.
Provides the status of the "Brigade Isol-" PIN (J8-3) of the
Brigade Signalling Interface. S/C to 0V gives the state
ActiveInput and an O/C gives the Normal state.
Provides the status of the "SGD FLT+" PIN (J8-5) of the
Brigade Signalling Interface. S/C to 0V gives the Normal state
and O/C gives the Fault state.
Point is unused but included for future enhancement.
LED1 is the "FAULT" LED (LD1). The Operate state can be
controlled with system or user logic to turn the LED on or off. In
the event that the system is started with no valid configuration
data file then this LED is controlled by the system to toggle
every 2 seconds (1/4Hz).
