Vigilant MX1 Operator Manual Document: LT0344
Page 11-4 8 August 2017 Issue 2.4
Point Number
Point Text
Description
241.17
LED2
LED2 is the "A" LED (LD2). The Operate state can be
controlled with system or user logic to turn the LED on or off.
241.18
LED3
LED3 is the "B" LED (LD3). The Operate state can be
controlled with system or user logic to turn the LED on or off.
This LED is currently used as a diagnostic LED by system logic.
It is toggled every 3 passes of logic to indicate output logic is
running.
241.19
LED4
LED4 is the "C" LED (LD4). This LED is currently used as a
diagnostic LED by the system. It is toggled approximately every
500ms to indicate the system is operating normally. This LED is
not available for use by the user.
241.20
CALLPT
Shows the state of the manual call point input (J3-3). Fault is
>0.95V (O/C), Normal is 0.35-0.95V (2K7 ELD), Alarm is
<0.35V.
241.21
DOOR
Provides the status of the door input which uses a clean contact
switch to monitor the door open/closed status. Normal (closed)
is S/C to 0V, ActiveInput (open) is O/C.
241.22
FW WR EN
Provides the status of the "Firmware Write Enable" jumper.
ActiveInput when jumper is fitted, Normal when not fitted.
241.23
DB WR EN
Provides the status of the "Database Write Enable" jumper.
ActiveInput when jumper is fitted, Normal when not fitted.
241.24.0
Batt Voltage
Point is unused but included for future enhancement.
241.24.1
PSU I
Point is unused but included for future enhancement.
241.24.2
PSU V
Point is unused but included for future enhancement.
241.25.0
Mains
Provides the state of the mains power supply to the panel. This
point is placed into Fault when the mains power has failed, and
Normal otherwise.
241.25.1
Batt Low
Indicates battery voltage low level. Point will be in Fault when
the battery voltage drops below the threshold set in the
configuration, and Normal otherwise.
241.25.2
Batt Conn
Indicates battery connectivity. The state is Normal if the battery
is found to be connected or Fault if the battery is disconnected
or very discharged.
241.25.3
Earth
Indicates earth monitoring fault condition. Point will be in Fault
when an earth fault is detected, Normal otherwise.
241.25.4
Battery Test
Indicates battery test state. Point will be in ActiveInput when
battery test is active, Normal otherwise.
241.25.5
VBF1 Fuse
Provides the status of the fuse (F3) protecting the ANC1 power
supply (J4-1). Normal indicates the fuse is intact, Fault indicates
that the fuse has blown or is not fitted.
241.25.6
VBF2 Fuse
Provides the status of the fuse (F4) protecting the ANC2 power
supply (J5-1). Normal indicates the fuse is intact, Fault indicates
that the fuse has blown or is not fitted.
241.25.7
VBF3 Fuse
Provides the status of the fuse (F5) protecting the ANC3 power
supply (J6-1). Normal indicates the fuse is intact, Fault indicates
that the fuse has blown or is not fitted.
241.25.8
RZDU Fuse
Provides the status of the fuse (F2) protecting the RZDU power
supply (J24-1). Normal indicates the fuse is intact, Fault
indicates that the fuse has blown or is not fitted.
241.25.9
Battery
Capacity
Indicates that the long-term battery test has failed. Point will be
in Fault while test is running and has failed, Normal otherwise.
241.25.10
VNBF Fuse
Provides the status of the fuse (F6) protecting the non-battery
backed power supply (J15-1). Normal indicates the fuse is
intact, Fault indicates that the fuse has blown or is not fitted.
