RESETF3 resets the point, including any latched states and turns
off any TestOp state.
P241.8.0 |
Ancillary Relay 1 | DISABLE
| RESET
TestOp |
Fig 6-26 – Output Point - Test in Progress
While the Operate Test is active, the test options are:
DISABLEF2 will disable the point. If the point is already disabled
this option will be ENABLEF2.
RESETF3 resets the point (stopping the test), including any latched
states.
The point is not automatically disabled by this test, so
testing some outputs may activate external equipment such
as sounders, door releases or even fire suppression
equipment.
Also, at most 10 detector LEDs can be turned on at the
same time. Testing more than 10 simultaneously will still
pass, just the LED will not turn on.
This function requires Access Level 2.
MX1 translates sensor readings into analogue values. These values are
processed by algorithms to determine the status of the point. The raw
values, equivalent levels measured in physical units (for example, ppm
CO,
o
C Temperature, % Obscuration, % Alarm) and algorithms for a
point can be recalled on the display.
These are intended for device fault or performance diagnosis, and are
not very meaningful without a good understanding of the system.
Viewing Point Values and Settings
