Vigilant MX1 - Disabling and Enabling Points or Zones

Vigilant MX1 Operator Manual Document: LT0344
Page 6-6 8 August 2017 Issue 2.4
F1 is then pressed, the prompt “1.1._” will appear.
Once the point number(s) are entered, press OK and you will then be
asked to select the reset option. Refer to “Resetting a Point” (page 6-4)
for details of the point reset options.
Reset point range | FULL
P1.1.1-1.1.3 | HISTORY
| TRACK
Select reset option or CANCEL |
Fig 6-9 – Selecting The Reset Option
Press FULLF1, HISTORYF2 or TRACKF3. You will then be asked
for confirmation. Press OK.
The configured points in the range will be reset for the selected option.
The display will then show the recall point status display for the first point
in the selected range. Use the menu options to navigate through the
point range, or press CANCEL to return to the base display.
If no points are configured in the selected range, the message “No Valid
Points Selected” will be shown briefly.
In general, each zone, each device, and each point may be disabled to
stop conditions on the item affecting the system. For example, the
smoke sensor point of an 814PH detector may be disabled to stop alarm
monitoring for smoke while certain building work is going on around the
detector. This will leave the heat sensor point still operational and able to
detect alarms.
Disabling a device by entering the equipment and device number (i.e., no
subpoint) will normally disable all sensor or input subpoints. With these
subpoints disabled, a detector may be completely removed from the loop
with the consequential fault condition(s) masked by disable.
Where it is required to disable only a particular element of the sensor,
e.g., heat or smoke, then the relevant subpoint only should be disabled.
Note that although device fail conditions are signalled from subpoint 0,
fault conditions will still be signalled from other sensor input subpoints if a
device is removed with only subpoint 0 disabled.
Disabling and Enabling Points or Zones
Description of
Operation
