Vigilant MX1 - Chapter 4 Viewing the Event History; General Message Format

Document: LT0344 Vigilant MX1 Operator Manual
Issue 2.4 8 August 2017 Page 4-1
The MX1 maintains a history of the 900 most recent events that have
occurred. These are stored in non-volatile memory, so are not lost on
power down. When the history is full, the oldest event is deleted so a
new event can be added.
Topic
See Page
General Message Format
4-1
Viewing Event History
4-2
Zone Events
4-3
Point Events
4-5
System Events
4-6
When contacting technical support services, ensure that the
event message shown on the MX1 LCD is quoted exactly as
shown.
Each message in the Event History shows a change in the state of some
system component, for example a zone or a point. The message shows
the new state, the component that changed, and the time and date when
the change was registered.
09:23:11 15/01/10 | OLDEST
Point 241.1.0 | PREV
Enabled | NEXT
Alarm Alerting Devices | NEWEST
Fig 4-1 – Event History Message
In this example, the message is saying that at 9:23:11 am on 15
th
January 2010, the point numbered 241.1.0, representing the Alarm
Devices, was enabled.
There are three types of event message:
 System, where line 2 of the display says “Local event”
 Zones, where line 2 of the display says “Zone nnn”
 Points, where line 2 of the display says “Point Eq.Dev.Sub”.
The following sections describe these in more detail.
Chapter 4
Viewing the Event History
Introduction
In this Chapter
General Message Format
