Document: LT0344 Vigilant MX1 Operator Manual
Issue 2.4 8 August 2017 Page iii
MORE
INFO
Key
– Function Key
F1 displays
additional
alarm
information. Th
is includes
the alarm
type
, zone action text, the
current level o
f the device causing the alarm
, and the time at
which the alarm occurred.
SILENCE
BUZZER
Key
– is used to silence the internal
buzzer in the panel
if it is on.
SILENCE ALARMS Keyswitch
– operating this switch
deactivates the alarm alerting devices (the Alarm Devices
indicator goes out). The FAULTS indicator will light and the fault
buzzer
may
sound (continuous
ly).
When this switch is restored to normal, all current alarms will be
automatically
disabled/isola
ted (the
DISABLES
indicator will light)
and the alarm detail display will be replaced by the general fault
display.
EVACUATION Keyswitch
– operating this switch activates the
alarm alerting devices.
SERVICES RESTORE Keyswitch
– operating this switch rest
ores
selected building services to normal operation after a fire alarm
(dependent on system configuration)
.
Other keys
- While the door is shut and the key turned fully
clockwise, all other keys on the keypad cannot be used.
Fire Fighter
’s Interface
– New Zealand Operation
– Quick Reference
Alphanumeric Display
– shows alarm detail: alarm type, zone/
point number, zone location and point location.
It also shows which alarm is being displayed and what the total
number of alarms is.
General FIRE Indica
tor
– is lit if there is any
unisolated alarm, whether brigade calling or not.
SEVERAL ALARMS Indicator
– lit when there are
2 or more
ala
rms
present
. Press
NEXT
to view
additional alarms
.
Alarm Devices Indicator
(red)
– is lit when the
alarm alerting
devices (sounders, evacuation system
, etc
.) are
activated.
Alarm Routing
Indicato
r (red)
– is lit when a Fire
signal is being transmitted to the brigade signalling device.
NEXT
Key
– steps the alarm display forward to the following
alarm. The
F3
key h
as the same effect.
ACK Key
– Function Key
F4
marks an alarm as acknowledged
in the alphanumeric display. Acknowledgement of an alarm
may make the corresponding flashing zone alarm indicator go
steady and may acknowledge the alarm at a remote display.
PREV Key
– Function Key
F2
steps the alarm display
backwards to the previous alarm.
