Wacker Neuson G 240 - Trailer Wiring Components

wc_tx003652gb_FM10.fm
219
Mobile Generator General Machine Schematics
25.3 Trailer Wiring Components
Ref. Description
1 Front right side amber light
2 Front left side amber light
3 Trailer plug
4 Battery
5 Brake solenoid
6 Right tail light
7 License plate holder lights
8 Left tail light
9 Rear right side red light
10 Rear left side red light
Ref. Wire Colors Rear Lights Side Lights Harness
B BLACK Ground Ground Battery charge
Br BROWN Tail light Tail, side and license plate
L BLUE
R RED Brake light Power Electric brakes
Y YELLOW Left brake light and directional
G GREEN Right brake light and directional
W WHITE Ground
